BENTLY 3500/94M 184826-01B is a VGA display module within the Bently Nevada 3500 monitoring system. Here are its detailed specifications.
1. Product Definition

The BENTLY 3500/94M 184826-01B is a VGA display module designed for the Bently Nevada 3500 monitoring system. It serves as a core human-machine interaction component of the system, responsible for visually presenting real-time monitoring data of mechanical equipment.

2. Data Sheet & Parameters

Brand/Manufacturer: Bently Nevada

Dimensions: Approximately 24.13 cm × 2.44 cm × 24.18 cm (9.50 in × 0.96 in × 9.52 in)

Weight: About 0.91 kg

Country of Origin: United States

I/O Modules: Optional position I/O modules with internal terminals (e.g., proximitor, RPT, DC LVDT)

Humidity Resistance: 95% relative humidity, non-condensing

Operating Temperature: -30°C to +65°C (-22°F to +150°F)

Storage Temperature: -40°C to +85°C (-40°F to +185°F)

Rack Space Requirement: 1 full-height front slot

3. Operating Principle

The 3500/94M VGA display module utilizes a standard color VGA monitor with touchscreen technology to present data from the 3500 system. It consists of three main components: the 3500/94M VGA display module itself, its associated I/O modules, and the VGA display monitor.

The display monitor can be installed at a maximum distance of 6.1 meters (20 feet) from the rack via a standard cable, enabling flexible placement in control rooms or on-site observation areas.

The 3500/94M module is configured using the 3500 Rack Configuration Software. It supports customization of up to 9 screens; by default, one bar graph screen displays all 1x filtered vibration measurements, and another screen shows the gap values of proximity sensors—allowing operators to quickly access key equipment status data.
