ABB CCF10-P (3BDH000508R1) is a high-performance Modbus coupling module for ABB DCS/SIS platforms, enabling seamless serial-to-Ethernet protocol conversion and reliable data exchange in industrial automation. As a core communication gateway, the CCF10-P integrates legacy Modbus RTU/ASCII devices with modern Modbus TCP networks, critical for process control, power, and oil & gas systems.

Key Features

Modbus Protocol Conversion: Transparent bridge between Modbus RTU/ASCII (serial) and Modbus TCP (Ethernet); supports master/slave modes.

Multi-Interface Connectivity: RS-232/RS-422/RS-485 serial ports (galvanic isolation); 1× Ethernet 10/100 Mbps for TCP/IP.

Industrial-Grade Reliability: Rugged metal housing; surge/EMI protection; -20°C to +60°C operation; IP20 protection.

Easy Configuration: Built-in web server for setup; supports 300–19200 baud rates; multi-TCP connection support.

Seamless ABB Integration: Compatible with ABB 800xA, Symphony Plus, Freelance DCS; ideal for S800 I/O and AC800M controllers.

Technical Specifications

Applications

Power Generation: DCS communication for turbine control, boiler safety, and substation monitoring.

Oil & Gas: ESD system data exchange, pipeline monitoring, and offshore platform automation.

Chemical & Petrochemical: Process safety control, furnace/BMS integration, and legacy device connectivity.

Industrial Automation: Factory floor I/O networking, SCADA integration, and remote monitoring solutions.

Why Choose ABB CCF10-P 3BDH000508R1

The ABB CCF10-P 3BDH000508R1 is a robust Modbus coupling module that ensures reliable, high-speed data transfer between serial and Ethernet networks. Its rugged design, wide temperature range, and seamless ABB DCS/SIS compatibility make it essential for critical industrial applications, reducing downtime and enhancing system interoperability.

ABB CCF10-P, 3BDH000508R1, ABB Modbus coupler, CCF10-P coupling module, ABB DCS communication gateway, Modbus TCP/RTU converter, industrial automation module, ABB 800xA interface.
