ABB LD810HSE EX 3BSE091722R1 Explosion-Proof FF HSE Linking Device | ABB 800xA DCS Fieldbus Gateway
Original ABB LD810HSE EX 3BSE091722R1 FOUNDATION Fieldbus HSE linking device, ATEX/IECEx hazardous area certified, 4-channel FF-H1, DIN rail mount, compatible with ABB 800xA DCS, 12-month global warranty, in stock.
The LD810HSE EX 3BSE091722R1 is an ABB factory-original EX-rated FOUNDATION Fieldbus linking device designed as a gateway between FF-HSE high-speed Ethernet subnet and FF-H1 fieldbus links， Developed for ABB Ability 800xA and AC 800M distributed control systems, this explosion-proof communication module delivers stable bidirectional data exchange between hazardous-area field instruments and central control consoles. Registered as Class 42c per HSE protocol specifications, it supports full device redundancy, real-time process data republishing, alarm forwarding and unified time synchronization for explosion-risk industrial sites
H2: Core Product Key Features
- EX hazardous area design, certified ATEX & IECEx for Zone 1/2 gas and Zone 21/22 dust explosive environments
- 1 x auto-sensing HSE Ethernet port (10/100 Mbps RJ45) + 4 independent FF-H1 channels (31.25 kbit/s)
- Built-in LAS Link Active Scheduler for each H1 link, publisher/subscriber cyclic data transmission
- Full redundant operation with independent failover link between primary and secondary units
- Transparent remote configuration, parameter access and live list scanning of all FF-H1 field devices
- Supports cross-link data republishing between H1 channels and bidirectional H1-HSE data transfer
- DIN rail compact mounting, IP20 protection for indoor explosion-proof cabinet installation
- Wide temperature tolerance: -40°C ~ +70°C operating range, anti-condensation humidity resistance
- Complete self-diagnosis with LED status indicators for communication, power and fault alerts
- Conformal coated circuit board for anti-corrosion in harsh industrial plant environments
H2: Full Technical Specification Table
| Parameter | Detailed Parameter Data |
|---|
| Part Number | LD810HSE EX 3BSE091722R1 |
| Manufacturer | ABB Industrial Automation |
| Product Type | FOUNDATION Fieldbus HSE Linking Device (Gateway) |
| Control System Compatibility | ABB 800xA DCS, AC 800M Controller Series |
| Communication Ports | 1 x HSE 10/100Mbps Ethernet RJ45; 4 x FF-H1 31.25kbit/s Fieldbus |
| Power Supply | 24V DC SELV/PELV (18–32V DC), typical input current 200mA |
| Hazardous Certification | ATEX, IECEx (Zone 1/2 gas, Zone21/22 dust) |
| Mounting Method | Standard DIN Rail Mount |
| Protection Grade | IP20 (Indoor Cabinet Use Only) |
| Operating Temperature | -40°C ~ +70°C |
| Storage Temperature | -40°C ~ +85°C |
| Working Humidity | 10%–95% Non-Condensing |
| Max Installation Altitude | ≤2000 Meters Above Sea Level |
| Net Weight | 0.25 KG |
| Dimension | 105mm × 100mm × 35mm |
| Conformal Coating | Anti-corrosion PCB coating for chemical & marine sites |
H2: Industrial Application Scenarios (Long-Tail SEO Keywords Embedded)
- Oil & gas refineries, offshore platforms and natural gas pipeline control systems
- Petrochemical plants, chemical reactor and distillation unit DCS communication
- Pharmaceutical factories with flammable solvent batch process automation
- Coal chemical and fertilizer manufacturing hazardous zone monitoring
- Power plant auxiliary process control with explosive gas risk
- Hazardous area FOUNDATION Fieldbus instrument network expansion & retrofitting
- Old ABB Advant OCS / 800xA DCS system maintenance spare parts replacement
H2: Supply & After-Sales Service Information
- Product Condition: Brand new original factory sealed, full function factory testing before shipment
- Stock Status: Ready global stock, fast delivery within 3–8 working days worldwide
- Quality Warranty: 12-month full hardware failure warranty with global technical support
- Supporting Documents: Official ABB datasheet, installation wiring diagram, 800xA system matching manual
- Technical Support: Free remote compatibility consultation and fieldbus configuration guidance
- Bulk Order Policy: Custom volume discount for plant maintenance and EPC project procurement
H2: SEO FAQ Section for Long-Tail Search Ranking
Q1: What is the core function of ABB LD810HSE EX 3BSE091722R1?
A1: It acts as an explosion-proof FOUNDATION Fieldbus gateway bridging FF-HSE high-speed Ethernet and 4-channel FF-H1 fieldbus links, enabling safe data communication between hazardous-area field transmitters, valves and ABB 800xA DCS control systems.
Q2: Can LD810HSE EX operate in redundant architecture?
A2: Yes, it fully supports simplex and dual redundant configurations with dedicated redundancy monitoring links for zero-failover reliable operation in critical process plants.
Q3: Which ABB control systems match LD810HSE EX 3BSE091722R1?
A3: Compatible with ABB Ability 800xA distributed control platform and AC 800M series controllers, widely used as spare parts for existing FF fieldbus network upgrades and maintenance.
Q4: Does LD810HSE EX support installation in explosive hazardous zones?
A4: Yes, it holds ATEX and IECEx explosion safety certifications, suitable for Zone 1/2 gas and Zone 21/22 dust dangerous industrial environments when installed inside certified flameproof cabinets.
If you need genuine ABB LD810HSE EX 3BSE091722R1 FF fieldbus linking device for hazardous area DCS retrofits, plant maintenance or EPC project spare part stocking, send your inquiry to get instant stock quotation, global freight plan and free system compatibility verification. Our industrial automation engineering team provides 24/7 online fieldbus technical support.
