Product Overview

Model: SPHSS13. The ABB SPHSS13 hydraulic servo module, originally Bailey product, is an upgraded replacement for IMHSS05, designed for Symphony Plus / INFI90 Harmony DCS rack system. As a critical DEH servo main control card, SPHSS13 performs local closed‑loop calculation with LVDT valve position feedback after receiving DCS command signals. It outputs driving current for servo valves to precisely control steam turbine governor valves, main steam valves and water turbine wicket gates for unit speed and load regulation. Widely used in thermal power plant DEH digital electro‑hydraulic control system, SPHSS13 is a vital industrial spare part for 300MW,600MW coal‑fired power units and combined‑cycle power plants for maintenance and retrofitting projects. SPHSS13 supports PI and P‑Only control algorithm with local loop response less than 10ms. Redundant servo coil outputs and redundant LVDT feedback inputs enable bumpless switch‑over under fault conditions to improve power unit safety performance.

Technical Specifications

Key Features

ABB SPHSS13 is engineered for Symphony Plus Harmony platform, high‑speed backplane bus communication, directly compatible with INFI90 rack without extra converters.

On‑board local servo closed‑loop calculation reduces main processor burden, delivers fast and high‑precision turbine valve positioning with control accuracy up to ±0.1%.

Dual‑redundant design with redundant servo coil outputs and redundant LVDT position feedback. Single point fault will not cause actuator malfunction, meeting safety requirements of critical power plant equipment.

Comprehensive hardware self‑diagnosis monitors short‑circuit, overload and sensor failure, fast fault location to minimize plant downtime.

Rugged industrial hardware with strong EMC performance for dusty and high‑EMI cabinet environment in power stations, ideal for power plant spare‑part replacement and system retrofitting.

ABB SPHSS13 hydraulic servo module available in stock, fast delivery. Please send inquiry for quotation.
