GE IS200JPDFG1AED is a DC power distribution module manufactured by General Electric (GE), belonging to the Mark VIe series. Below is an introduction to its specifications, application scenarios, and operating principle:

1. Specifications

Input Voltage: 125V DC

Output: Capable of providing three non-switched fused outputs and six switched fused outputs.

Circuit Protection: Equipped with a 125V DC 30A circuit breaker, a line filter, and 18 fuses with independent power ratings.

Feedback Function: Provides status feedback such as bus voltage detection, ground fault detection, and excessive AC voltage detection on the DC bus via the PPDA I/O interface.

2. Application Scenarios

It is mainly used in industrial automation control systems, particularly in the power generation field—such as control systems for gas turbines, steam turbines, and generators. It supplies stable DC power to other circuit boards and equipment in these systems, ensuring the reliable operation of the entire control system.

3. Operating Principle

The IS200JPDFG1AED module receives redundant 125V DC power input. The power first passes through a 125V DC 30A circuit breaker and a line filter, then is distributed to three non-switched fused outputs and six switched fused outputs. The power from these outputs is routed to the DACA module, where AC power is converted to DC power. The DC power is then returned to the JPDF module and combined with the battery power input.

The JPDF module can operate with any combination of one or more active inputs, thereby providing highly reliable 125V DC power for the control system. Meanwhile, the module offers comprehensive status feedback through the PPDA I/O interface to ensure stable system operation and fault detection.
